Electric Single Phase Power Source Customized YCS-101 Stationary Power Source

Name: Electric Single Phase Power Source Customized YCS101 Stationary Power Source
Brand: GENY
Price: 1 USD

Certification : ISO, CE

Supply Ability : 100/Year

Payment Terms : L/C, T/T, D/P

Brand Name : GENY

Model Number : YCS-101

Place of Origin : CHINA

Model NO. : YCS-101

Display : Digital

Installation : Direct Connected

Usage : Multi-Functional Energy Meter, Watt-Hour Meter, Meter for Industry and Home Use, Standard Electric Energy Meter, Prepayment Meter, Reactive Energy Meter, Multi-rate Watt-hour Meters, Maximum Demand Meter

Electric Equipment : Single-phase

Theory : Electronic Meter

Power Meter Connection : Terminal

Measured Signal : Pulse Peak

Type : Energy Meter

Customized : Customized

Trademark : GENY

Transport Package : Plywood Case

Specification : 0.672CBM

Origin : China

HS Code : 9030849000

Port : Guangzhou, China

Contact Now

Single-phase Electric Equipment Customized Ycs-101 Stationary Power Source

Product Description

YCS-101Single Phase Power Source

Output separate voltage and current signal, suit for single phase energy meter.
High accuracy and high stability output.
With RS232 interface for automatic operation.
With keyboard for manual operation(optional).
2nd-41st harmonic,output amplitude and degree can be programmed.
Aluminum alloy material,light and strong, prevent corrosion.
With the protect function of overload, short voltage circuit and open current circuit.
Simple control software,easy for operation.
The power source is accredited to conforms to EU health and safety standards with CE certificates

Product Parameters

Application Conditions and Requirements
Environment			Power Requirement	Safety
Operation Temperature	Humidity	Altitude	Voltage Supply	IP Class	Conformity
-10ºC--+40ºC	35%--85%	<2500m	3x220/380V±10%(or customized)	IP30	CE conform
			50/60Hz±2Hz

Type	YCS-101-250	YCS-101-600	YCS-101-1200	YCS-101-2500
Voltage
Test voltage output(Phase-Neutral)	24V-300 V or customized
Power of the voltage output	Max.100VA	Max.250VA	Max.500VA	Max.1000VA
Resolution	Better than 0.01% of full scale value of range
Setting accuracy	Better than 0.05% at the final range value
Stability	Better than 0.005%/h (integration time 150 s)
Load regulation from 0-max.load	Better than 0.01%
Distortion factor	Better than 0.3% for linear resistance load
Harmonics	2nd-41st free programmable
Current
Test current output	1mA-120A/200A
Power of the current output	Max.250VA	Max.500VA	Max.1000VA	Max.2000VA
Resolution	Better than 0.01% of full scale value of range
Setting accuracy	Better than 0.05% at the final range value
Stability	Better than 0.005%/h(integration time 150 s)
Load regulation from 0-max.load	Better than 0.01%
Distortion factor	Better than 0.3% for linear resistance load
Harmonics	2nd-41st free programmable
Phase angle
Range	0-360°
Resolution	0.01°
Setting accuracy	0.1°
Frequency
Range	45Hz-65Hz
Resolution	0.01Hz
Error display
Type of error display	Red LED
Resolution of the error displays	8 digits

Company Profile

Guangzhou Yangcheng Science & Technology Enterprises Co., Ltd., founded in 1987, stands as a prominent multi-industry enterprise group. Our annual sales volume reaches several hundred million RMB across a diverse range of sectors, including electrical measuring equipment, industrial and domestic automation engineering, biological engineering, and commercial trade. Our workforce has grown to 464 employees, with 156 dedicated professionals focused on the manufacturing and business operations of electrical measuring equipment.
In a strategic move in 2002, our electric measurement department evolved into a distinct entity, Guangzhou GENY Electric Co., Ltd., a wholly-owned subsidiary recognized as a high-tech company with a specialization in the innovation and production of advanced electricity measuring equipment.
Today, we proudly position ourselves as one of China's foremost and most influential manufacturers in the electrical measuring equipment domain. Our track record includes the successful deployment of over 7,000 energy meter test benches and an impressive 10,000 portable calibrators within the Chinese market, a testament to our commitment to quality and innovation.

Our main products of electrical measuring equipment

Single/Three Phase Electric Energy Meter Test Bench
Single/Three Phase Portable Standard Meter
Single/Three Phase standard meter
Single/Three Phase Power Source
Single/Three Phase Portable Power Source etc.

Our Advantages

We have been engaged in the Electric Energy Meter measurement field for over twenty years as an all-time technological leader and creator of new technology in the Electric Energy Meter calibrator field. We have an excellent R&D team that has devoted to the technical development of Electric Energy Meter test instruments for a long time, we can satisfy different requirements of all kinds of customers.
All of our staff have received specialized training and acquired good professional quality and skills. The company adopts ISO9001 management and we have passed the authentication of ISO9001-2000 in 2002 and all staff has taken TQM training. Yangcheng has now realized ISO9001 control of R&D production, marketing & sales, and service completely to guarantee product quality.
We have a consummate marketing network and we offer a competitive price.
Our well-trained service team is able to provide maintenance, training, scheme design, and software update services to each customer for the first time.
